Customized 1200W series 12V 50A 24V 30A 36V 20A 48V 20A 60V 15A 72V 12A battery charger for Lead acid Lithium or LifePO4 battery

Customized 1200W series 12V 50A 24V 30A 36V 20A 48V 20A 60V 15A 72V 12A battery charger for Lead acid Lithium or LifePO4 battery
  • Продавец
  • Список ценUS $202.10piece
  • Продажная ценаUS $202.10piece
  • ДоставкаБесплатная доставка
  • Рейтинги3,4 (662)

Oписание продукта

12V 80A  Universal lead acid battery charger,Negative Pulse Desulfation battery charger

CLEN-B1280:12V 80A
Input Voltage:  110VAC OR 220VAC, 50-60HZ
Charging Voltage:  14.7V or adjust to battery\'s specification
Charging Current:  80A(MAX)
Ambient Temperature:  0째C TO +40째C
Cooling:  Fan cooling
Charger Type  :7-step,full automatic switch mode,(reverse) pulse charging
Appropriated Battery : 12V lead acid battery,AGM,AGL
Battery Capacity : 240-600AH
Dimensions : 310*210*95mm
Net Weight : 4.5 kg




Main Features:

1. Automatic Charging

MCU system is applied. The whole charging process is monitored. Multi-stage
charging is automatically proceeded. Automatically stops charging when the
battery is full. You can leave the charger connected to the battery indefinitely
without the risk of overcharging; Once the battery is full, the charger monitors the
battery voltage and intermittent to float charging the battery if the capacity of your
battery lower than our charger\'s preset digital.

2. Compact and convenient

Small and light as we adopt the switch mode technology Or we call Switching
Power Supply, this is different from Linear Power using in traditional charger.
More than 85% electric energy was transferred to battery chemical energy during
charging process comparing with 40% of conventional charger. The tech is
suitable for all types of batteries (wet, maintenance free, VRLA, AGM, etc)

3. Digital Display and More Protection

Voltmeter and Ammeter will show battery\'s voltage on display screen.
LED indicators will show pulse and reverse pulse charging as well as how much
Polarity Protection: Prevents the output leads from sparking due to accidental
reverse connection or short circuit,
Overcharge Protection: never worry about overcharging as charger
automatically stops when battery is full.
High Temperature Protection: If charger itself gets to high temperature, it will
automatically lower down its temperature even stop working so that charger is
well protected.

4. Maintain battery and recover it\'s capacity

Pulse and reverse pulse charging technology is applied. The charger generates
pulse and reverse pulse to reduce battery impedance, gassing and temperature
rise, restore the sulfate into liquid to recover battery capacity. So that the charger
can maintain battery and prolong its lifetime.


We can change parameter to meet different applications. Make charger specially
for your battery.

6. CE and RoHS Certification

We have CE and RoHS certification.
